LINEAR CAGE FORMING TUBE MILL VAI 89.5(6) with universal CTA forming
Specifications:
- Manufacturer: VAI Voest Alpine Industrieanlagenbau
- Round tube diameter: 33.7 - 88,9 mm
- Square tube: 30x30 - 70x70 mm
- Rectangular tube: 40x20 - 100x40 mm
- Thickness: 0.8 – 5.0 mm (6.0mm with S235J2)
- Speed: 100 m/min
Complete line with:
- Double expandable mandrel with PEELER OTO AD408 SD
- Strip entry line with strip opener, driven pinch-roll, pre-leveller and lateral guiding rolls
- Automatic strip joiner
- Intermediate strip guding stand
- Break down section
- Forming section : Universal CTA Forming section VAI CTA90
- Fin pass section
- Welding section
- Double Cooling tunnel
- Sizing section
- Off-Line sizing stands
- Turk-head section
- Motorised Exit roller conveyor
Scope of supply:
1. Double expandable mandrel with PEELER OTO AD408 SD
- Strip width 500mm
- Hydraulic expansion
- Snubber roll top/bottom
- 8 Tn/arm
- Pneumatic servocontrolled brake
2. Strip peeler
- Strip opener
3. Strip Guiding
4. Break down section
- 2 motorised stands
- Monoblock casted stands
- Hydraulic gauge compensation and quick setup
- Shaft diameter 89mm
- Mechanical SIKO indicator
- Total installed power 106 kW
5. Forming section
- Universal CTA Forming section VAI CTA90
6. Fin pass section
- 2 motorised FP with rafted quick change
- Monoblock casted stands
- Hydraulic gauge compensation and quick setup
- Shaft diameter 89mm
- Mechanical SIKO indicator
- Total installed power 106 kW
7. Welding section
- 4-roll configuration
- Heavy duty welding head with lateral and top adjustment
8. Double Cooling tunnel
- 2 x 4000mm With V-rollers support
9. Sizing section
- 4 motorised sizing cages
- Total installed power 260kW
- With quick-change rafted stands
- SIKO bottom and top indicators
10. Off-Line sizing stands
- 4 motorised sizing cages
- Total installed power 260kW
- With quick-change rafted stands
- SIKO bottom and top indicators
11. Turk-head section
- 3 turk-heads
- Heavy duty changing plates
12. Complete set of rolls
Specifications
| Manufacturer | VAI SEUTHE Voest Alpine Industrieanlagenbau |
| Model | Tube Mill CTA 90×5 with universal forming CTA Forming |
| Year | 2026 |
| Condition | Refurbished |
| Stock Number | 2946 |
| Round tube diameter | 33.7 - 88,9 mm |
| Square tube diameter | 30x30 - 70x70 mm |
| Rectangular tube diameter | 40x20 - 100x40 mm |
| Thickness | 0.8 – 5.0 mm (6.0mm with S235J2) |
| Speed | 100 m/min |
