EVG Welding mesh line | model SLW 12/94 – RV

Technical data:

Mesh width max.: 2600mm

Mesh length max.: 8000mm

Cross wire pitch min.: 50mm then continuous

Longitudinal wire pitch: 100mm, 150mm, 200mm, 300mm

Cross wire diameter: min. 4mm - max. 8.5mm

Longitudinal wire diameter: min. 4mm - max. 12mm

Max. welding power: (D=100mm) E + F = 20.5mm

Machine speed (see operating diagram): max. 130 QD/min

Wire spool weight: max. 3000kg

Stacking height: max. 650mm

Stacking weight: max. 4000kg

Electrical data:

Nominal power of welding transformers: 1500 KVA at 50% of the duty cycle

Drive power: 355KVA

Mains voltage: 3 x 400V

Mains frequency: 50 Hz

Status:

Line currently still in production.

Manufacturer	EVG
Model	SLW 12/94 – RV Welding mesh line
Condition	Used
Stock Number	4018
Mesh width max.	2600 mm
Mesh length max.	8000 mm
Cross wire pitch min.	50 mm then continuous
Longitudinal wire pitch	100 mm, 150 mm, 200 mm, 300 mm
Cross wire diameter	4 - 8.5 mm
Longitudinal wire diameter	4 - 12 mm
Max. welding power	(D=100 mm) E + F = 20.5 mm
Machine speed (see operating diagram)	max. 130 QD/min
Wire spool weight	max. 3000 kg
Stacking height	max. 650 mm
Stacking weight	max. 4000 kg
Nominal power of welding transformers	1500 KVA at 50% of the duty cycle
Drive power	355 KVA
Mains voltage	3 x 400V
Mains frequency	50 Hz
